• The product is mainly applicable to a power system of AC 50Hz (or 60Hz), rated working voltage up to 230V, and in a line of application class AC-7a with rated working voltage up to 230V and rated working current up to 20A. It is used to remotely close or/and switch off the line. The product is widely used in dwelling houses, hotels and so on.
• The product is in conformity with the standards: GB 17885 IEC 1095

Normal operation and mounting requirement

• Circumstance temperature -5°C ~ +40°C, average temperature within 24h not exceeding +35°C.
• Altitude above sea level less than 2000 m.
• Humidity not exceeding 50% at 40°C and not exceeding 90% at 25°C.
• Installation class II
• Pollution class 2.
• Installation method DIN Rail mounting type.
• Product shall be vertically mounted onto standard Din rail 35mm.

Technical Data:
Rated current(In):20,25,40,63,80,100A
Rated operational voltage(Ue):230/240VAC,400/415VAC
Number of module:1M,2M,3M
Rated frenquency:50/60Hz
Utilization category:AC1,AC3,AC7a,AC7b,AC5b
Electrical endurance:150,000cycles(AC1,AC7a,AC3,AC7b)
Mechanical endurance:1,000,000cycles
Rated insulation voltage(Ui):500VAC
Rated impulse withstand voltage(Uimp):4KV
Terminal:pillar type
Cable termination:16/25mm2
Torque of screw:1.2/2Nm
IP degree:IP20
Standard:IEC/EN61095,IEC/EN60947-1

Catalog No. CTN Size:46.5x24x17.5CM

Ratings

Making and breaking capacity

Conventional operating performances

Product Dimension
