Electrical Circuit Breaker EDF 401004 Differential 500 mA Selective 2P 60

1. Application

The DDC breaker is divided into 2 poles and 4 poles. It can be applied to the circuit breaker installed on the control panel of the primary equipment, and can also be applied to the control terminal of the shopping mall, base station and home power supply board.

Feature as below:

1)This product has a high level of safety protection.

2)Not affected by ambient temperature.

3)Multi-step adjustable of rated current.

4)Rated current digital display.

5)With anti-stealing function

2.Specification and Configuration

caractéristiques techniques du produit disjoncteur différentiel largeur en nombre de modules 4 profondeur dencastrement 51 mm nombre de pôles protégés 1 nombre de pôles total 2 degré de pollution 2 pôle neutre sectionné simultanément oui immunisé contre déclenchements intempestifs non type de tension ac tension assignée ue 250 v adapté à une installation encastrée oui type de courant différentiel ca calibrecourant nominal assigné in 60 a sensibilité courant de défaut nominal iδn 0.5 ma tenue au courant de choc 0.25 ka fréquence 50 hz indice de protection ip ip40 caractéristique de déclenchement typecourbe autre section de raccordement cable souple 1-16 mm² section de raccordement cable rigide 1-25 mm² pouvoir de coupure nominal selon en 61009-1 icn 2.4 ka avec dispositif de verrouillage oui pouvoir de coupure assigné selon en 61009 2.4 ka tension disolement assignée ui 4000 v commentaires

Electrical Circuit Breaker EDF 401004 Differential 500 mA Selective 2P 60

Outshell and installation dimensions

Electrical Circuit Breaker EDF 401004 Differential 500 mA Selective 2P 60

DDC BACO Adjustable circuit breaker.pdf
